- NEW smart crimping control (SCC)
- Ergonomic design
- Compact size
- Impressively high crimping force
Finn-Power P32CS SCC
Hose size up to 2”
Crimping Range – Up to 87mm
200 tons of crimping force
Finn-Power PP32CS CSS has been designed for service van use. CS machines are battery powered with 12V or 24V, crimping head on left as standard.
New Smart Crimping Control (SCC) brings smartness and connectivity for service and workshop machines. It is easy to use with features such as diameter crimping, recipes and data recording. A magnetic attachment makes it easy to change the place of control.
For the Finn-Power P32CS CSS crimping machine the maximum hose size is 2″ and the machine can be equipped with seventeen standard die sets.
Standard Inclusions
Smart Crimping Control
(SCC)
Optional Extras
Quick Change Tool
Mechanical Back Stop device
Electrical Back Stop Device
Foot Pedal
Technical Data
| Description | P32CS SCC |
|---|---|
| Crimping Range dia (mm) ₁ | 10-87 |
| Max. crimping force (kN) | 2000 |
| Number of crimping/cycle time 10 mm ₂ | 21.1 |
| Hose size ID (inch) | 2 |
| Die Set ₃ | P32 |
| Max. opening (mm) | +33 |
| Master die D/L (mm) | 99 / 80 |
| Control | SCC |
| Motor (kW) ₃ | 1.6 / 2.2 |
| Oil tank volume (Litres) | 5 |
| Size: Length (mm) | 601 |
| Size: Width (mm) | 457 |
| Size: Height (mm) | 558 |
| Weight incl. oil (kg) | 139 |
Key:
- With standard dies. Crimping range can be increased with special dies.
- Theoretical with 100mm cycle
- 12 V / 24 V. Overload controlled
Standard Die Sets
| Part Number | Crimping Range (mm) | Length (mm) |
|---|---|---|
| 18506/10 | 10.0 – 12.0 | 55 |
| 18506/12 | 12.0 – 14.0 | 55 |
| 18506/14 | 14.0 – 16.0 | 55 |
| 18506/16 | 16.0 – 19.0 | 55 |
| 18506/19 | 19.0 – 22.0 | 55 |
| 18506/22 | 22.0 – 26.0 | 70 |
| 18506/26 | 26.0 – 30.0 | 70 |
| 18506/30 | 30.0 – 34.0 | 70 |
| 18506/34 | 34.0 – 39.0 | 75 |
| 18506/39 | 39.0 – 45.0 | 75 |
| 18506/45 | 45.0 – 51.0 | 90 |
| 18506/51 | 51.0 – 57.0 | 90 |
| 18506/57 | 57.0 – 63.0 | 100 |
| 18506/63 | 63.0 – 69.0 | 110 |
| 18506/69 | 69.0 – 75.0 | 110 |
| 18506/74 | 74.0 – 80.0 | 110 |
| 18506/78 | 78.0 – 87.0 | 110 |
In addition to the standard die sets, a wide range of special die sets for different diameters, lengths and forms is available.
